| Output Power |
3000W max at Single input, 6000W max at Dual input, 7800W max at Quad input |
| Output Voltage |
+12.9V & +5.1V |
| Line regulation |
+/-0.3V |
| Load regulation |
+/-0.3V |
| Ripple & Noise |
< 250mV pk-pk |
| Rise time |
<100ms |
| Turn On Delay |
< 2 sec |
| Dynamic response |
Output shall be within+/-550mV outside droop range for current step change of 50% -100% of full load. |
| Over current protection |
115-125% of Full load |
| Short circuit protection |
Shall provide hiccup type of protection with 3 re-tries and shutdown the main output. |
| Over voltage protection |
Latching Type |
| Current share |
Active current share |
| EEPROM & I2C bus |
PS with a serial EEPROM communicates information to the system processor through I2C bus |
| Microcontroller |
PSU remote shut off, LED status monitored and controlled through microcontroller. |
| Thermal protection |
PWM Converter disabled when the internal temperature exceeds safe operating range |
| Under voltage |
Capable to withstand any input under voltage for unlimited time without damage. |
| Power Fail signal |
A Negative True Open collector signal. Issues Power Fail Signal |
| Fan fail |
Power Fail signal also indicate warning of an internal fan failure |
| Hot swapping |
Hot swappable |
