| Output Power |
2200W max at input range |
| Output Voltage |
12V & 12V standby |
| Line regulation |
+/-3% |
| Load regulation |
+/-5% |
| Ripple & Noise |
< 120mV pk-pk |
| Rise time |
<100ms |
| Turn On Delay |
< 3 sec |
| Dynamic response |
Output shall be within+/-5% of it’s final value for 10% load to 60% load. |
| Over current protection |
110%-130% of Full load |
| Short circuit protection |
Protected for continuous short circuit. Recovery after removal of short circuit. |
| Over voltage protection |
Latching Type |
| Current share |
Active current sharing method |
| EEPROM & I2C bus |
PS with a serial EEPROM communicates information to the system processor through I2C bus |
| Microcontroller |
PSU remote shut off, LED status monitored and controlled through microcontroller. |
| Thermal protection |
PWM Converter disabled when the internal temperature exceeds safe operating range |
| Under voltage |
Capable to withstand any input under voltage for unlimited time without damage. |
| Power Fail signal |
A logic low True Open collector signal. Issues Power Fail Signal 1mS before O/P goes out of Regulation |
| Fan Fail |
Power Fail signal also indicate warning of an internal fan failure |
| Hot swapping |
Hot swappable |
