| Output Power |
5000W max at Single input, 5500W max at Dual input |
| Output Voltage |
12.3V & 5.1V |
| Line regulation |
+0.4V/-0.35V |
| Load regulation |
+0.4V/-0.35V |
| Ripple & Noise |
< 250mV pk-pk |
| Rise time |
<100ms |
| Turn On Delay |
< 2 sec |
| Dynamic response |
Output shall be within+/-600mV outside droop range for current step change of 50% -100% of full load. |
| Over current protection |
115-125% of Full load |
| Short circuit protection |
Protected for continuous short circuit. Recovery after removal of short circuit. |
| Over voltage protection |
Latching Type |
| Current share |
Active current share |
| EEPROM & I2C bus |
PS with a serial EEPROM communicates information to the system processor through I2C bus |
| Microcontroller |
PSU remote shut off, LED status monitored and controlled through microcontroller. |
| Thermal protection |
PWM Converter disabled when the internal temperature exceeds safe operating range |
| Under voltage |
Capable to withstand any input under voltage for unlimited time without damage. |
| Power Fail signal |
A Positive True Open collector signal. Issues Power Fail Signal |
| Fan fail |
Power Fail signal also indicate warning of an internal fan failure |
| Hot swapping |
Hot swappable |
