| Output Power |
2200W max at input range |
| Output Voltage |
56V |
| Line regulation |
+/-0.05% |
| Load regulation |
+/-5% |
| Ripple & Noise |
< 500mV pk-pk |
| Rise time |
< 50ms |
| Turn On Delay |
< 3 sec |
| Dynamic response |
Output shall be within+/-450mV of the ideal value under a load transient from 10% to 100% with 50% of rated load step and 0.25A/us slew rate. |
| Over current protection |
106%-116.5% of Full load |
| Short circuit protection |
Protected for continuous short circuit. Recovery after removal of short circuit. |
| Over voltage protection |
Latching Type |
| Current share |
Active current sharing method for V1 |
| EEPROM & I2C bus |
PS with a serial EEPROM communicates information to the system processor through I2C bus |
| Microcontroller |
PSU remote shut off, LED status monitored and controlled through microcontroller. |
| Thermal protection |
PWM Converter disabled when the internal temperature exceeds safe operating range |
| Under voltage |
Capable to withstand any input under voltage for unlimited time without damage. |
| Power Fail signal |
A logic low True Open collector signal. Issues Power Fail Signal 1mS before O/P goes out of Regulation |
| Fan Fail |
Power Fail signal also indicate warning of an internal fan failure |
| Hot swapping |
Hot swappable |
